Mine Spec C4 LED Cube Light (flood)
EXPLOSIVE PERFORMANCE.
We gave our engineers the instruction to hold nothing back. The result? A class-leading CREE XM-L2 emitter, producing 4,200 lumens of light intensity. With the explosive performance that it delivered; we had no choice but to call it the ‘C4’.
DIVERSE USAGE.
The C4 allows you to choose from 3 variations of beam options: spot, flood or diffused. With each variation possessing a unique field of usage and luminance, the Industrial C4 Flood will help you build the perfect lighting setup for the required application.
CERTIFIED IP68.
The C4 Diffuse LED Light is built to withstand the harshest conditions. With sealed dust protection and protection against water submersion of up to 3m, you can trust the C4 Diffuse LED Light to deliver in any environment.
The nitty
gritty.
Mine Spec C4 LED Light Cube | Flood
- 4 x CREE XM-L2 5700K
- Environmentally sealed and moulded Deutsch DT-2 connector with male wire tail included
- RFI and EMI suppressed circuity ensure no interference with sensitive radio equipment
- Fitted with Gore Breather Vent – Certified IP68 | Submersible to 3m
- 304 Series Stainless Steel Bracket and Fasteners
Beam Characteristics
- Spot Beam: Relentless we’re still shocked every time we turn it on – Potent enough to take on the task of stealth driving light.
- Diffused Beam: A homogeneous flood beam that is smooth and almost cloudy in light distribution making it an ideal near-field work light, reverse, or camp light.
- Wide Beam: The wide beam produces a deeper flood beam in comparison to diffuse, better suited to applications requiring a longer throw flood beam.
- Dual Lens: Providing a useful flood beam when a large area of clear visibility is required with the addition of a 650nm (red)/1500k (amber) diffused beam ideal for working under without dazzling your eyes.
Tech Specs
| LED POWER OUTPUT | 4 x 10w LEDs |
| LUMENS | 4,200Lm |
| OPERATING VOLTAGE | 12v & 24v Compatibility |
| OPERATING TEMPERATURE | -40°C to 60°C |
| IP RATING | IP68 |
| LED | CREE XML2 |
| COLOUR TEMPERATURE (CCT) | 5700K |
| MATERIAL | Die Cast Aluminium Housing |
| LENS | Lexan Optical |
| MOUNTING BRACKET | Stainless Steel U-Bracket |
| BOLTS AND FITTINGS | Included |
| BEAM TYPE | Flood |
| LIFE SPAN | 50,000 Hours |
| AMP DRAW | 2.1A @ 13.6v |
| WEIGHT | 0.550kg |
What's Included
- 1 x Mine Spec C4 LED Cube Light (flood beam)
- Shock Dampeners
- Stainless U Mounting Bracket
- Mounting Hardware
- Male and Female Deutsch Connectors
